Y Series Patch Fitting

Y SERIES PATCH FITTINGPenopang Pintu Kaca Y Series

Bottom Door Patch to suit Floor Springs

Model No.

P010

Product Description

Yale Bottom Door
Patch to suit Floor Springs

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Top Door Patch to suit 15mm Pivot

Model No.

P020

Product Description

Yale Top Door
Patch to suit 15mm pivot

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Top Patch to suit Transform Closer (side load)

Model No.

P022

Product Description

Yale Top Patch to suit
Transom Closer (side load)

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Top Patch with 15mm pivot

Model No.

P030

Product Description

Yale Top Patch with
15 mm pivot

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Top Patch for over and side panel with 15mm pivot

Model No.

P040

Product Description

Yale Top Patch for over
and side panel with 15 mm pivot

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Patch for over panels, side panel with fin fitting (Handed Left or Right)

Model No.

P041L/P041R

Product Description

Yale Patch for over panels,
Side panel with fin fitting Left/Right

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Over panel and side panel for double or single swing doors without stops

Model No.

P060/P061

Product Description

Yale Over panel and side panel
for double or single swing doors

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Connector for over panel and side panel with stop

Model No.

P062

Product Description

Yale Connector for over
panel and side panel with stop

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Over panel connector with stop inserts

Model No.

P070

Product Description

Yale Over panel
connector with stop inserts

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Corner Lock suits Europrofile Cylinder. Bolt has 20 mm projection

Model No.

L010

Product Description

Yale Corner Lock suits Euro
Profile Cylinder

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Centre lock suits Europrofile cylinder. Bolt has 20mm projection.

Model No.

L020

Product Description

Yale Centre Lock suits Euro
Profile Cylinder

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Double over panel strike box. Suits L010 Corner locks.

Model No.

S020

Product Description

Yale Double over panel strike
box (Suits L010 Corner locks)

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Single over panel strike box. Suits L010.

Model No.

S030

Product Description

Yale Single over panel strike
box (Suits L010 Corner Locks)

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Corner over panel strike box.

Model No.

S040

Product Description

Yale Corner over
panel strike box

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32

Universal strike box. Suits L020.

Model No.

S050

Product Description

Yale Universal strike box
(Suits L020 Centre Locks)

Finish

Satin Stainless Steel – US32D
Polished Stainless Steel – US32
